Y-type filter media transmission pipeline system is indispensable to a filter device, Y-type filter is usually installed in the valve, pressure relief valve, water valve or other device set the import side, the medium used to remove impurities to protect the valves and equipment for normal use. Y-filter with advanced structure, small resistance, sewage and convenient. Y-type filters suitable medium for water, oil and gas. Generally through the water network from 18 to 30 mesh, ventilation network of 10 to 100 mesh, through the oil to 100 ~ 480 mesh net. Basket filters are mainly taken over by the supervisor, the blue filter, flange, flange, and fasteners and other components. When the blue liquid into the filter through the head, the solid impurity particles in the filter was blocked in blue, and clean blue fluid through the filter from the filter outlet exhaust.
Please specify when ordering: product name, nominal size, pressure rating, material, flange standard, operating pressure, media and other detailed parameters. Product size is more than conventional general-purpose, other specifications for size, welcome to contact us
